The RENNtech V3 Digital Lowering Module (DLM) is designed to work with all available Mercedes Airmatic or ABC (hydraulic) suspensions. The unit allows its user to have full control over all four corners of the vehicle’s suspension and adjust it in 1mm increments. Check out the video below to see the installation process and controls of the RENNtech V3 DLM.
The DLM requires no splicing or soldering to the factory wiring harness. The RENNtech harness utilizes the factory pins to allow a convenient and completely reversible installation. The unit also supports speed-dependant lowering that allows the vehicle to return to its factory ride-height at a pre-set speed. This process removes the need for the vehicle to be aligned after its been lowered. The user can maintain the factory longevity and still have the lowered look at low speeds.
All RENNtech DLMs are adjustable via USB using either Windows or Android OS. The software has three locations where the user can store pre-configured suspension setups for quick and effortless changes.
Note: On the SL 550 (R231) the ABC suspension system is optional equipment from the factory. The ABC suspension system is required for the digital lowering module (DLM).
RENNtech VAG V3.5 DLM Module Specifications:
- Current Consumption: 30mA (60mA while plugged in to PC/Tablet)
- Adjustment increments: 1mm
- Maximum Lowering: Limited only by vehicle
- Adjustment Methods: PC or Android (Tablet)
- Size: 53mm x 73mm x 24mm
- Weight: 1.2oz
RENNtech V3 DLM Installation Video:
