ARP Bolts M12 x 1.75 x 45 Hex Black SS Bolts 14mm Socket 98 ft-lbs Torque (5/pkg) - 765-1005

ARP Bolts - Part Number: 765-1005

If you're in the market for reliable fasteners, the ARP Bolts 765-1005 is a solid choice. Known for their attention to detail and quality, ARP has been at the forefront of fastener technology since 1968. This particular set includes five M12 x 1.75 x 45 Hex Black Stainless Steel bolts, designed to withstand the high demands of performance applications.

These bolts are engineered to handle extreme loads, making them ideal for critical diesel applications. Many users appreciate the high installation pre-loads, which means these fasteners are designed to stretch during installation for a secure fit. One customer noted, "I used these bolts in my diesel setup, and the difference in performance was noticeable. They hold everything tight without any issues." This feedback reflects the trust that many have in ARP products.

Specifications:

  • Socket Size(s): 14mm hex
  • Torque Value: 98 ft-lbs (132.9 Nm)
  • UHL: 45mm
  • Thread Length: 30mm
  • Grip Length: 15mm
  • Thread Diameter-Spacing: M12 x 1.75mm
  • Grip Diameter: 12mm
  • Wrenching: 14mm
  • Head Height: 11.7mm
  • Collar Diameter: 21.6mm

In terms of durability, the black stainless steel finish not only adds a sleek look but also enhances corrosion resistance, ensuring that these bolts will last through the toughest conditions. Another user mentioned, "The finish on these bolts is fantastic. They not only perform well but look good too." This combination of strength and aesthetic appeal makes the ARP 765-1005 an excellent addition to any serious mechanic's toolkit.

Whether you're upgrading your current setup or building something new, the ARP Bolts 765-1005 is worth considering for its quality and reliability.

Proposition 65

⚠ WARNING: Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov

ARP Bolts Logo

The Story Behind ARP Bolts

ARP (Automotive Racing Products) was founded by Gary Holzapfel in 1968 when he noticed his drag-racing friends succumbing to bolt-induced engine failure as a result of poor-quality fasteners. He drew upon his expertise in the aerospace industry to develop a solution, which turned into a successful business nonetheless.

Since its inception, ARP has been engineering and perfecting a wide range of bolts, studs, nuts, and other fasteners for engines, cylinder heads, headers, wheels, and transmissions. Today, ARP remains the undisputed world leader in automotive fasteners. Racing aficionados everywhere know and recognize the ARP brand and can vouch for its quality.

What Makes ARP Bolts So Special?

Located in Ventura, California, all ARP processes from raw wire to finished fasteners are conducted in-house, right here in the USA. The company continually improves its processes with strict quality control guidelines and is dedicated to producing products that are second to none. Simply put, ARP Bolts are better than the competition because of their quality materials and advanced processes.

ARP prides itself on using only top-quality materials that are above the usual “aerospace-grade” quality that other manufacturers settle for. For example, while 8740 Chromoly steel has four different grades, ARP only uses the top two, SDF and CHQ. These grades cost twice as much as the lower commercial and aircraft grades, but deliver “zero defect” quality that you can trust each and every time.

ARP Bolts are built to withstand serious racing, possess greater tensile strengths, and can survive higher stress levels than most aircraft fasteners. ARP is dedicated to creating fasteners that boast ultimate strength and durability to ensure they last race after race. Its product lineup ranges from quality high-performance OEM parts to exotic specialty hardware for IndyCar, NASCAR, NHRA drag racing, Formula 1, and even marine applications.

Equip Your Ride with ARP Bolts at Vivid Racing

If you are looking to change the fasteners on your car, you’ve come to the right place. No other brand beats out ARP Bolts in terms of strength, quality, and race-proven success. Vivid Racing is, therefore, proud to carry an extensive lineup of products from American Racing Products like bolts, fluids, sealants, hand tools, stud kits, piston sleeves, wheel bolts, and more! If you have any questions regarding the parts above, please call our specialized sales team at (480) 966-3040.
