Blitz Damper Zz-R Toyota Prius PHV GR SPORT 2017-2022 - 92368
Blitz have become one of the leading tuners in Japan due to the fine detail and superior workmanship of their products. Their parts look stylish and sleek, but they are constantly refined to maximise the power output from your engine. For the highest quality, but also the best performing parts, get Blitz.

Product Details:
  • Mount F/R: Reinforced rubber / Ask
  • Rate F/R(kgf/mm): 4.0 / 4.0
  • Free length F/R: 220 / 255
  • Spring F/R: ID62 straight spring / Barrel or Taper type exclusive spring
  • Height adjustment range F/R: -62 to 0 / -52 to -20
  • *The range is when adjusting the height on the lower bracket side. *Adjustment range may change due to grade, vehicle weight... etc. *Even within the range, it may interfere with the inner fender and others. Also, please check the minimum ground clearance and set the height.
  • Rear damping dial Position & Shape: B *Refer to the 5th image for the position and shape. The image is representative model.
  • Extension dial with the product: 150mm *
  • Stabilizer link with the product F/R: FF / x
  • BRAIN connection: x
  • Remarks: Drilling upper iron panel of upper mount and resin service panel for installation of front extension dial , Rear damping dial is in wheel well
Product Features:
  • Single cylinder type (monotube) structure. The entire length adjustable suspension kit.
  • Reasonable price.
  • 32 levels damping force adjustment mechanism was adopted, it allows a wide range damping force adjustment. For all driving scene from the street use to car racing.
  • Aluminum upper mount, lock seat, the bracket (except some models) achieve both high strength and light weight.
  • 44 diameter piston of the single-cylinder type suppress damping force lag.(except for some models)
NOTE:
  • It is possible malfunctions some devises with radar, camera, sensor etc. by installing DAMPER ZZ R series. It is also possible that malfunctions such as safety equipment, collision avoidance support equipment, driving assistance equipment of each car manufacturer may occur.
  • When installing the DAMPER ZZ-R series, especially in the case of the strut type suspension, the shock absorber may interfere with even genuine wheels and tires.
  • This item may require an extra shipping charge depending on the destination country. If it does, we will contact you by email within 3 business days after the order is placed and tell you how much extra it costs for shipping. You can ask us to cancel the order if you would not like to pay the difference. We will proceed with the order once we receive the extra payment from you.
Fitment:
  • Toyota Prius PHV GR SPORT 2017-2022
