If you’re looking to upgrade the dashboard of your classic Ford Pickup from 1967 to 1972, the Dakota Digital Series III instrument system is a solid choice. This isn’t just about looks; it’s packed with tech that makes driving a lot more enjoyable and informative. The high-brightness vacuum fluorescent displays are not only easy to read but also built to last. You won’t have to worry about them fading or malfunctioning on you.

This full 6-gauge system fits right into your existing bezel (though the bezel isn’t included, just a heads up). It’s a straightforward swap that gives your ride a modern touch while keeping that vintage vibe intact.

Specifications:

• Speedometer: Measures from 0 to 255 MPH (there’s a metric version too, if you prefer km/h).
• Tachometer: Ranges from 0 to 17,500 RPM, perfect for those who love to push their engines.
• Oil Pressure: Monitors from 0 to 99 psi, so you’ll always know how your engine’s doing.
• Water Temperature: Keeps tabs from 0 to 300°F (or 0 to 150°C for the metric folks).
• Fuel Level: Shows from 0 to 99%, making it easy to keep an eye on your tank.
• Voltmeter: Covers 8 to 17 VDC, ensuring your electrical system is in check.
• Standard Colors: Choose between a cool blue or a vibrant teal.

Digital Message Centers:

• Odometer: One-time user settable, and it can track up to a million miles—because who doesn’t want that?
• Trip Meter: Dual (A/B) trip meter that goes up to 9,999.9 miles.
• Performance Meters: Includes a 0-60 MPH timer, 1/4 mile time, and trap speed, so you can track your performance on the road or track.

Built-in Indicators:

• Turn signals, high beam, check engine, parking brake, and cruise control indicators are all included.
• Additional gear position and 4x4 indicators can be added if your setup requires them.
• Just a note: not all OEM indicator functions will transfer over, so if you need more indicators, you might need to repurpose some of your old ones.

Included Sensors:

• Water Temperature Sensor: Comes with a 1/8" NPT, ground-isolated sensor and a 10 ft harness.
• Oil Pressure Sensor: A solid-state sensor with the same 10 ft harness.
• Speed Sensor: Replaces Ford/GM style cables with a 10 ft harness, but make sure you have about 5 inches of clearance for installation.
• Bushings: Comes with a variety of bushings to fit different NPT sizes and metric threads.

Control Box Dimensions:

• 5.5" x 3.5" x 1" — compact enough to fit in most setups.

Calibration:

• Easy push-button calibration makes it a breeze to set up your speedometer, cylinder count, and fuel level gauge. Once you’re set up, those same buttons give you access to all the data in the Digital Message Centers.

Fitment:

• Specifically designed for the 1968 Ford Mustang.

So, if you're ready to give your classic ride a tech upgrade that’s both functional and stylish, this Dakota Digital system could be just what you need. It’s got the features to keep you informed and the reliability to last.
