Get to Know the Dakota Digital Series III Instrument System

If you’re looking to upgrade the dashboard of your classic ride, the Dakota Digital Series III is where it’s at. This isn’t just some flashy gadget; it’s a solid piece of tech that’s built to last. With high-brightness vacuum fluorescent displays, you’ll get crystal-clear readings no matter the time of day. Plus, it’s designed for accuracy and reliability—no more guessing if you’re running low on fuel or pushing the limits on RPMs.

What’s in the Box?

This full 6-gauge instrument system comes with a sleek billet aluminum dash housing that fits perfectly in 1951-52 Chevy models. It’s like giving your classic a modern twist while keeping that vintage vibe intact.

Specifications That Matter

• Speedometer: Readings from 0 to 255 MPH (or 0 to 255 km/h if you prefer metric).
• Tachometer: This bad boy goes up to 17,500 RPM—perfect for those who love to push their engines.
• Oil Pressure: Monitors from 0 to 99 psi, so you can keep an eye on your engine health.
• Water Temperature: Ranges from 0 to 300°F (or 0 to 150°C if you’re metric-minded).
• Fuel Level: Tracks from 0 to 99%, so you’ll know when it’s time to fill up.
• Voltmeter: Covers 8 to 17 VDC, keeping tabs on your electrical system.

Digital Message Centers

These gauges aren’t just pretty faces; they come with some serious functionality:

• Odometer: Million-mile capacity, and you can set it once to your liking.
• Dual Trip Meter: Track two trips at once, with a range of 0-9,999.9 miles.
• Performance Meters: 0-60 MPH timer, 1/4 mile time, and end speed—perfect for those of us who like to see how we stack up.

Built-in Indicators

Stay informed with built-in indicators for:

• Turn Signals (Left/Right)
• High Beam
• Check Engine
• Parking Brake
• Cruise Control (if equipped)
• Gear Position (optional sensor required)
• 4x4 (if equipped)

Just a heads up: not all OEM indicator functions will transfer over, so if you need more, consider repurposing any unused indicators.

Included Sensors

Each kit comes with everything you need:

• Water Temperature Sensor: 1/8" NPT, with a 10 ft harness.
• Oil Pressure Sensor: 1/8" NPT solid state, also with a 10 ft harness.
• Cable Driven Speed Sensor: Replaces GM-style speedometer cables, and requires about 5" of clearance for installation.
• Bushings: You’ll get a variety of bushings to fit different sizes.

Easy Calibration

Setting this up is a breeze. Just mount the included push buttons somewhere handy, and you can calibrate your speedometer and set cylinder counts with a few clicks. Once you’re all set, those same buttons let you dive into the wealth of data from the Digital Message Centers.

Fitment

This gauge system is tailored for:

• Chevrolet Fleetline 1951-1952
• Chevrolet Styleline Deluxe 1951-1952
• Chevrolet Styleline Special 1951-1952

So if you’re looking to give your classic Chevy a modern touch without losing its soul, the Dakota Digital Series III is definitely worth checking out.
