So, you've got your hands on a classic ride and you're looking to bring it into the modern age without losing that vintage charm? The MHX-51F is your go-to solution. It fits right into your stock gauge bezel, making installation a breeze. No need to chop up your vintage tin—just attach it to the original mounting points and you're good to go. If you want to kick it up a notch, check out the VLC-51F, which is a slick clock/message center that comes in a chrome-plated, machined aluminum body. It’s a perfect match for the MHX series.

What really sets the MHX series apart is the attention to detail. Those fully lit needles and backlit faces are not just for show—they make it super easy to read your gauges at a glance. And let’s talk about the tech under the hood: micro-controlled precision stepper motors combined with solid-state sensors give you accuracy that’s hard to beat. Plus, you can customize the display feedback to suit your style. And, if you’re worried about longevity, Dakota Digital backs this with a limited lifetime warranty, which is pretty much the gold standard in the industry.

Everything’s engineered and manufactured in Sioux Falls, South Dakota, so you know you’re getting quality craftsmanship. The MHX series has really shaken things up in the instrumentation world, giving you the modern functionality you need without sacrificing that classic vibe.

Specifications:

• Analog Gauges:
  • Speedometer: 0 - 120 MPH (or 0-195 km/h if you prefer metric)
  • Tachometer: 0 - 8,000 RPM
  • Oil Pressure: 0 - 80 psi
  • Water Temperature: 100 - 260°F (or 40-120°C for metric)
  • Fuel Level: E, 1/4, 1/2, 3/4, F
  • Voltmeter: 9 - 17 VDC
  • Lighting: Each gauge is lit with LEDs, ensuring you can see everything clearly, even in bright sunlight.
• Digital Message Centers:
  • Standard Displays:
    • Odometer (settable up to a million miles)
    • Dual Trip Meter (0-9,999.9)
    • 12-hour Clock
  • Performance Meters:
    • 0-60 MPH Timer
    • 1/4 Mile Time
    • 1/4 Mile End Speed
    • High Speed Recall
    • High RPM Recall
  • Gauges:
    • Speedometer (0-255 MPH/km/h)
    • Tachometer (0-9,900 RPM)
    • Oil Pressure (0-100 psi)
    • Water Temperature (100-300°F/40-150°C)
    • Voltmeter (9-17 VDC)
    • Fuel Level (0-99% full)
  • Lighting:
    • Auto-contrasting LCD for optimal visibility in sunlight.
    • LED backlighting for nighttime clarity.
• Built-in Indicators:
  • Turn Signals (Left/Right)
  • High Beam
  • Check Engine
  • Parking Brake
  • Cruise Control (On/Engaged)
  • Gear Position (requires optional GSS-3000 sensor)
  • 4x4 (if equipped)
  • Wait to Start (if equipped)
  • Note: Not all OEM indicator functions are replaced; consider repurposing unused indicators as needed.
• Included Sensors:
  • Water Temperature: 1/8" NPT, ground isolated sensor with a 10 ft harness.
  • Oil Pressure: 1/8" NPT solid-state sensor with a 10 ft harness.
  • Cable Driven Speed Sensor: Replaces Ford/GM style speedometer cables with a 10 ft harness. Needs about 5" clearance for installation.
  • Bushings: Comes with various NPT and metric bushings for easy installation.
  • Control Box Dimensions: 5.5" x 3.5" x 1"
• Calibration:
  • Easy pushbutton calibration for speedometer, cylinder count, and fuel level gauge. Just mount the buttons in a handy spot and you're set!

The MHX-51F-S-B Dakota Digital system is a solid investment for anyone looking to upgrade their gauges without losing that classic feel. It's a no-brainer for enthusiasts who want the best of both worlds.
