If you’re looking to breathe new life into your classic 1949-50 Ford, the VHX-49F gauge bezel is a game changer. Forget about refinishing your old bezel; this one comes in a slick, show-chromed billet aluminum finish that bolts right onto your stock dash points. It’s designed to fit seamlessly without any cutting, which is a huge plus for those of us who want to keep things as original as possible.

What sets the VHX Series apart? For starters, it’s packed with modern tech while still paying homage to that vintage vibe. You’ll notice fully lit needles and backlit faces that make reading gauges a breeze, even in bright sunlight. And let’s talk about the LCD message center—super clear and easy to digest at a glance. No more squinting at tiny numbers!

Inside, you’ll find precision stepper motors and solid-state sensors that deliver accuracy you can rely on. Plus, you can customize the display feedback to match your style. Dakota Digital backs this up with a limited lifetime warranty, which is pretty sweet considering the level of craftsmanship that goes into these gauges.

Specifications:

• Speedometer: 0-120 MPH (or 0-195 km/h if you prefer metric)
• Tachometer: 0-8,000 RPM
• Oil Pressure: 0-80 psi
• Water Temperature: 100-260°F (or 40-120°C for metric fans)
• Fuel Level: E, 1/4, 1/2, 3/4, F
• Voltmeter: 9-17 VDC
• Lighting: LED backlighting ensures you see every detail, no matter the conditions.

Digital Message Centers:

• Standard Displays:
  • Odometer (One-time user settable, up to a million miles)
  • Dual Trip Meter (0-9,999.9)
  • 12-hour Clock
• Performance Meters:
  • 0-60 MPH Timer
  • 1/4 Mile Time
  • 1/4 Mile End Speed
  • High Speed Recall
  • High RPM Recall
• Gauges:
  • Speedometer (0-255 MPH/km/h)
  • Tachometer (0-9,900 RPM)
  • Oil Pressure (0-100 psi in 1 psi increments)
  • Water Temperature (100-300°F / 40-150°C in 1° increments)
  • Voltmeter (9-17 VDC)
  • Fuel Level (0-99% full)
• Lighting:
  • Auto-contrasting LCD display for bright sunlight.
  • LED backlit for night use.

Built-in Indicators:

• Turn Signals (Left/Right)
• High Beam
• Check Engine
• Parking Brake
• Cruise Control (if equipped)
• Gear Position (requires optional GSS-3000 sensor)
• 4x4 (if equipped)
• Wait to Start (if equipped)

Included Sensors:

• Water Temperature: 1/8" NPT, ground isolated sensor with a 10 ft harness.
• Oil Pressure: 1/8" NPT solid state sensor with a 10 ft harness.
• Cable Driven Speed Sensor/Generator: Replaces Ford/GM style speedometer cables with a 10 ft harness. Needs about 5" clearance for installation.
• Bushings: Comes with various bushings for easy fitment.
• Control Box Dimensions: 5.5" x 3.5" x 1"

Calibration:

Setting up the VHX-49F is straightforward. You’ll get pushbuttons to calibrate your speedometer, set the cylinder count, and adjust the fuel level gauge—all easily accessible. Once you’re set up, those same buttons let you dive into all the info the Digital Message Centers have to offer.

Install Instructions:

• Wiring and Setup Manual
• Quick Start Manual
• VLK Operation Manual
• VLC/VLK Mounting Manual

Fitment:

• Ford Car 1949-1950

Note:

• Includes the new chrome bezel shown.
• Not all OEM indicator lamp functions will be replaced.
• If you need more indicators, think about repurposing any unused ones.
• Images are for representation only; the actual product may vary.

Overall, if you’re serious about upgrading your dash while keeping that classic look, the VHX-49F is where it’s at. It’s a solid investment for anyone wanting to keep their vintage Ford running smoothly and looking sharp.
