DS18 amassed a wealth of experience in manufacturing the most elegant neodymium midranges for those seeking simple perfection. Neodymium magnets provide a higher magnetic flux density in the air gap, which generates a much greater action force in the voice coil.
For this reason, Neo magnets have the strongest permanent magnets of all the commercially available speakers. Ranging in sizes, mounting depths, and frequency responses, we have more than 10 different models of Neo midranges to accommodate any build.
Specifications
For this reason, Neo magnets have the strongest permanent magnets of all the commercially available speakers. Ranging in sizes, mounting depths, and frequency responses, we have more than 10 different models of Neo midranges to accommodate any build.
Specifications
- Nominal Diameter: 8 inch (203.2mm)
- Nominal Impedance: 4 Ohms
- RMS Power Handing: 275 Watts
- MAX Power Handing: 550 Watts
- Sensitivity (1w/1m): 98dB
- Frequency Response: 65Hz - 22KHz
- Recommended Hi Pass Crossover: 80Hz
- Voice Coil Diameter: 1.5 inch (38.1 mm)
- Voice Coil Former Material: Kapton
- Winding Material: CCAW
- Basket Material: Steel
- Magnet Material: 27 oz
- Voice Coil Diameter: 1 inch
- Voice Coil Material: Kapton
- Winding Material: CCAW
- Diaphragm Material: Aluminum Alloy
- Magnet Weight: 0.44 oz
- Magnet Material: Neodymium (N38H)
- Thiele and Small Parameters
- Equivalent Volume / Vas 12.4021 LTR
- Excursion / Xmax 1.6mm
- Free Air Resonance / Fs 110 Hz
- Mechanical Factor / Qms 3.906
- Electrical Factor / Qtes 0.76
- Total Factor / Qts 0.708
- DC Resistance / Re 3.2 Ohms
- Overall Diameter: 214 mm (8.42 inch)
- Front Mount Baffle Cutout: 181 mm (7.13 inch)
- Mounting Depth: 91 mm (3.58 inch)
- Overall Depth: 113 mm (4.44 inch)
- For Instructions CLICK HERE!
Other Part Numbers:
DS18 #PRO-ZT8-FXVX
Proposition 65
⚠ WARNING:
Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov
DS18 is a company that is based in Miami, Florida, USA. The company specializes in manufacturing high-quality electronics used in different industries such as the marine, home electronics, and automotive industries. Today, DS18 is considered the leading manufacturer of sound system equipment in the market.
Wide Range Of Audio ProductsDS18 was developed and created by a group of young and passionate professionals who have a deep understanding of the needs of the audio industry. The company offers a wide range of products from speakers, amplifiers, subwoofers, midranges, tweeters, cables, accessories, component sets, and more. Over the years, DS18 has met the demands of many audiophiles around the world.
Well-Designed ProductsThe company has never stopped innovating its product offering by providing a unique and progressive product design that adapts to the ever-changing trend of the automotive industry. By getting their customer’s feedback, they can constantly improve their products which help them create the best sound system in the market today.
DS18 has revolutionized the market by offering trendy products that people love. Through constant research and development, DS18 was able to deliver the most outstanding products technology can offer.
Purchase DS18 Products At DS18If you are in the market for a high-quality sound system that would elevate how your in-car infotainment system would sound, then look no further as DS 18 is the brand for you. To know more about DS18 and what they can offer, visit Vivid Racing and check out their list of products that fit your specific requirement.
