Introducing the H13 2Stroke 4.0 LED Bulb

Get ready to transform your driving experience with the H13 2Stroke 4.0 LED Bulb! After a year of dedicated innovation, these bulbs bring a new level of clarity and safety to the road. The 2Stroke 4.0 features an impressive beam quality that mimics the original optics pattern while minimizing glare for oncoming traffic. With a sleek 1.45mm emission surface and advanced PCB technology, you can count on optimal performance every time you hit the road. Enjoy precise beam distribution with filament-sized accuracy, making every journey feel secure and well-lit. Plus, its adjustable base fits various reflectors, and the built-in cooling system ensures durability, even in extreme conditions. Upgrade your headlights now and light up your travels with confidence!

Benchmarking Excellence

While many in the industry may have been resting on their laurels, Morimoto has been hard at work crafting the successor to the fantastic 2Stroke 3.0 LED bulbs. The 4.0 re-creates the original beam pattern from your optics, delivering more light to the road while reducing glare for other drivers. Although LED bulbs aren't yet DOT approved for use in headlights in the U.S., those in foreign markets and fog light users can enjoy the best plug-and-play LED bulb available today?the 2Stroke 4.0, featuring patented technology by Morimoto.

Superior Beam Quality

The heart of the 2Stroke 4.0 is its advanced Aluminum Nitride Ceramic circuit board, allowing for the most precise beam pattern possible with a 1.45mm surface-emission interval. For context, the tungsten filament in a halogen bulb measures 1.4mm, while the previous record for LED bulbs was 2.0mm, set by the outgoing 2Stroke 3.0! Thanks to our industry-first ceramic PCB, we've eliminated the need for a dielectric layer and a separate thermal element, resulting in unmatched performance in all reflector and projector-based headlights designed for halogen bulbs.

Optimized Focal Length

Every bulb in the 2Stroke 4.0 lineup has been meticulously optimized for its intended application. We've calculated the critical reference distance based on the bulb base's geometry and the footprint of the Osram HJL531 emitter. To ensure consistency, we designed special tools to maintain quality control for each bulb as it rolls off the production line. Unlike many other LED bulbs that use a one-size-fits-all approach, the 2Stroke series guarantees optimal focus for every application.

360 Degrees of Rotation

Since there's no universal standard for headlight and fog light setups, all bulbs in the 2Stroke 4.0 range are fully adjustable. You can easily position the LED chips to sit perfectly at the 3 and 9 o'clock positions. The previous generation had issues with gears slipping during installation, but the new system is designed to prevent that. Aligning your bulbs has never been easier!

Thermal Management

The 2Stroke 4.0 features an upgraded version of the patented cooling system first introduced with the 3.0 bulbs. This unique design employs a 12,000-rpm dual-layer fan that pulls in cool air and expels warm air, keeping the bulb cool while warming the ambient temperature inside the housing. This innovative cooling method helps resist snow and ice buildup on the lens during winter. With even greater static pressure than before, the 2Stroke 4.0 maximizes bulb longevity while offering a weather-resistant benefit you won't find elsewhere.

Unique Drive Logic

The LED drivers are smartly programmed to start at a conservative 18W, gradually ramping up over the first 15 minutes to stabilize at 22.5W. Unlike other aftermarket bulbs that lose intensity during the initial warm-up period, the 2Stroke 4.0 maintains impressive performance from the moment you drive off until you park.

Lifetime Warranty

Crafted with the latest OE-grade materials, electronics, and LEDs, the Morimoto 2Stroke 4.0 bulbs are built to last. Their conservative LED drive rates and effective thermal management systems ensure low operating temperatures, all backed by an industry-leading lifetime warranty.

Features

• Designed & Engineered by Morimoto in California, packed with innovative features.
• Perfect Focus with ceramic PCB and Osram HJL LEDs for effective road illumination.
• Heat Exchanger that cools the bulb while warming the ambient temperature to resist snow/ice buildup.
• Lifetime Warranty, ensuring these bulbs are built to last.

Technical Specifications

• Luminous Flux: 2,600lm
• Power: 18-22.5W
• Input Voltage: 9V-16V DC
• Material: Electroplated Aluminum
• Current: 1.5-1.88A @ 12V DC
• Light Source: Osram Oslon Black Flat S 5500K (Pure White)

Compatibility

• BASE/FITMENT: H13
• Do I need PWM / Anti-Flicker Modules? When using in Fog Lights: Unlikely.
• With low beams that double as Daytime Running Light: Likely.
• With high beams that double as Daytime Running Light: Likely.
• When the vehicle is a late model American (Chrysler, Dodge, Jeep, Ford, GM): Likely.

Install Instructions

• For Instructions CLICK HERE
